NVIDIA ® RTX™ A5000

NVIDIA RTX™ A5000

  • SKU: VCNRTXA5000-PB
Where to Buy
  • Description

    NVIDIA RTX A5000

    Perfectly Balanced. Blazing Performance.

    NVIDIA RTX technology transformed the way professionals work by bringing the power of real-time ray tracing, AI, and advanced graphics to millions of designers, artists, scientists, and researchers. Now, the NVIDIA Ampere architecture paves the way for a new era of innovative products, immersive entertainment, life-saving discoveries, and breathtaking designs—powered by the second generation of NVIDIA RTX.

    Built on the NVIDIA Ampere architecture, the NVIDIA RTX A5000 perfectly balances power, performance, and memory to spearhead the future of innovation from your desktop. It combines 64 second-generation RT Cores, 256 third-generation Tensor Cores, and 8,192 CUDA cores with 24 GB of graphics memory to supercharge rendering, AI, graphics, and compute tasks. Connect two RTX A5000s for 48 GB of combined GPU memory with NVIDIA NVLink, unlocking the ability to work with larger models, renders and scenes, tackle memory-intensive tasks like natural language processing, and run higher-fidelity simulations to enhance your product development process. And support for NVIDIA virtual GPU software increases versatility for enterprise deployments. Realize your visions for the future today, with the NVIDIA RTX A5000.

    NVIDIA RTX a5000

    Highlights

    CUDA Cores 8192
    Tensor Cores 256
    RT Cores 64
    Single Precision Performance 27.8 TFLOPS
    RT Core Performance 54.2 TFLOPS
    Tensor Performance 222.2 TFLOPS
    GPU Memory 24 GB GDDR6 with ECC
    Memory Interface 384-bit
    Memory Bandwidth 768 GB/sec
    System Interface PCI Express 4.0 x16
    Display Connectors 4x DisplayPort 1.4a
    Maximum Power Consumption 230 W

    Incredible Application Performance

    Experience fast, interactive performance—powered by the latest NVIDIA Ampere architecture-based GPU—with ultra-fast, on-board graphics memory technology and optimized software drivers for professional applications.

    The NVIDIA RTX A5000 includes 64 RT Cores to accelerate photorealistic ray-traced rendering up to 2x faster than the previous generation. Hardware accelerated Motion BVH (bounding volume hierarchy) improves motion blur rendering performance by up to 7x when compared to previous generation.

    With 256 Tensor Cores to accelerate AI workflows, the RTX A5000 provides the power necessary for AI development and training workloads. Incredible inferencing performance, combined with enterprise-class stability and reliability, make RTX A5000-powered desktop workstations ideal for professional AI training and inferencing deployments.

    Scale application performance even more with NVIDIA NVLink technology that lets you combine two RTX A5000 cards to double the effective GPU memory and performance in a single workstation chassis to 48 GB.

    Ensure hardware compatibility and stability through NVIDIA support of the latest OpenGL, DirectX, Vulkan, and CUDA standards, deep independent software vendor (ISV) developer engagements, and certification with over 100 professional software applications.

    NGC support gives engineers, researchers, and data scientists access to NVIDIA-tuned, tested, certified, and maintained containers for the top deep learning frameworks, as well as third-party managed high-performance computing (HPC) containers, NVIDIA HPC visualization containers, and partner applications.

    Rich, Expansive Visual Workspace

    Experience stunning imagery through movie-quality, anti-aliasing techniques, high-dynamic range (HDR) color support, higher refresh rates, and up to 8K screen resolution at 60 Hz from a single cable with the DisplayPort 1.4a standard.

    Value for IT Administrators

    Experience higher-quality products driven by power-efficient hardware and components selected for optimum operational performance, durability, and longevity.

    Enjoy maximum uptime thanks to exhaustive product testing with leading OEMs and system integrators that simulates the most demanding real-world conditions.

    Remotely monitor and manage NVIDIA professional products in your enterprise by integrating the NVIDIA Enterprise Management Toolkit (NVWMI) in your IT asset management framework.

    Scale up NVIDIA RTX Enterprise driver deployment to hundreds of workstations using NVWMI’s powerful driver installer.

    Simplify software driver deployment through a regular cadence of long-life, stable driver releases based on a robust feature-development and quality-assurance process.

    NVIDIA NVLink

    • Scales memory and performance for the largest visual computing workloads
    • Faster than PCIe-based solutions and offers flexible configurations

    vGPU Software Support

    • NVIDIA Virtual PC (vPC)
    • NVIDIA Virtual Applications (vApps)
    • NVIDIA RTX Virtual Workstation (vWS)
    • NVIDIA Virtual Compute Server (vCS)
    • vGPU Profiles from 1 GB to 24 GB

    Resources


    Product Brochure
    NVIDIA Pro Graphics Comparison
    NVIDIA Power Guidelines
    Quadro and NVS Display Resolution Support

    Links


    Resource Center
    NVIDIA Pro Graphics Configurator

  • Features

    NVIDIA RTX A5000

    PERFORMANCE AND USEABILITY FEATURES

    NVIDIA Ampere Architecture

    The NVIDIA® RTX™ A5000 is the one of the most powerful workstation GPUs NVIDIA offers, bringing high performance real-time ray tracing, AI-accelerated compute, and professional graphics rendering to demanding professionals. Building upon the major SM (Streaming Multiprocessor) enhancements from the Turing GPU, the NVIDIA Ampere architecture enhances ray tracing operations, tensor matrix operations, and concurrent executions of FP32 and INT32 operations.

    CUDA Cores

    The NVIDIA Ampere architecture-based CUDA cores bring up to 2x the single-precision floating point (FP32) throughput compared to the previous generation, providing significant performance improvements for graphics workflows such as 3D model development and compute for workloads such as desktop simulation for computer-aided engineering (CAE). The RTX A5000 enables two FP32 primary data paths, doubling the peak FP32 operations.

    2nd Generation RT Cores

    Incorporating second generation ray tracing engines, NVIDIA Ampere architecture-based GPUs provide incredible ray traced rendering performance. A single RTX A5000 board can render complex professional models with physically accurate shadows, reflections, and refractions to empower users with instant insight. Working in concert with applications leveraging APIs such as NVIDIA OptiX, Microsoft DXR and Vulkan ray tracing, systems based on the RTX A5000 will power truly interactive design workflows to provide immediate feedback for unprecedented levels of productivity. The RTX A5000 is up to 2x faster in ray tracing compared to the previous generation. This technology also speeds up the rendering of ray-traced motion blur for faster results with greater visual accuracy.

    3rd Generation Tensor Cores

    Purpose-built for deep learning matrix arithmetic at the heart of neural network training and inferencing functions, the RTX A5000 includes enhanced Tensor Cores that accelerate more datatypes, and includes a new Fine-Grained Structured Sparsity feature that delivers up to 2X throughput for tensor matrix operations compared to the previous generation. New Tensor Cores will accelerate two new TF32 and BFloat16 precision modes. Independent floating-point and integer data paths allow more efficient execution of workloads using a mix of computation and addressing calculations.

    PCIe Gen 4

    The RTX A5000 supports PCI Express Gen 4, which provides double the bandwidth of PCIe Gen 3, improving data-transfer speeds from CPU memory for data-intensive tasks like AI and data science.

    Higher Speed GDDR6 Memory

    Built with 24 GB GDDR6 memory delivering up to 71% greater throughput for ray tracing, rendering, and AI workloads than the previous generation. The RTX A5000 provides a capacious graphics memory footprint to address the largest datasets and models in latency-sensitive professional applications.

    Error Correcting Code (ECC) on Graphics Memory

    Meet strict data integrity requirements for mission critical applications with uncompromised computing accuracy and reliability for workstations.

    5th Generation NVDEC Engine

    NVDEC is well suited for transcoding and video playback applications for real-time decoding. The following video codecs are supported for hardware-accelerated decoding: MPEG-2, VC-1, H.264 (AVCHD), H.265 (HEVC), VP8, VP9, and AV1.

    7th Generation NVENC Engine

    NVENC can take on the most demanding 4K or 8K video encoding tasks to free up the graphics engine and the CPU for other operations. The RTX A5000 provides better encoding quality than software-based x264 encoders.

    Graphics Preemption

    Pixel-level preemption provides more granular control to better support time-sensitive tasks such as VR motion tracking.

    Compute Preemption

    Preemption at the instruction-level provides finer grain control over compute tasks to prevent long-running applications from either monopolizing system resources or timing out.

    NVIDIA RTX IO

    Accelerating GPU-based lossless decompression performance by up to 100x and 20x lower CPU utilization compared to traditional storage APIs using Microsoft's new DirectStorage for Windows API. RTX IO moves data from the storage to the GPU in a more efficient, compressed form, and improving I/O performance.

    DISPLAY FEATURES

    NVIDIA Mosaic™ Technology

    Transparently scale the desktop and applications across up to 4 GPUs and 16 displays from a single workstation while delivering full performance and image quality.

    DisplayPort 1.4a

    Support up to four 5K monitors @ 60Hz, or dual 8K displays @ 60Hz per card. The RTX A5000 supports HDR color for 4K @ 60Hz for 10/12b HEVC decode and up to 4K @ 60Hz for 10b HEVC encode. Each DisplayPort connector can drive ultra-high resolutions of 4096x2160 @ 120 Hz with 30-bit color.

    NVIDIA RTX Desktop Manager

    Gain unprecedented end-user control of the desktop experience for increased productivity in single large display or multi-display environments, especially in the current age of large, widescreen displays.

    NVIDIA Quadro Sync II

    Synchronize the display and image output of up to 32 displays from 8 GPUs (connected through two Sync II boards) in a single system, reducing the number of machines needed to create an advanced video visualization environment.

    Frame Lock Connector Latch

    Each frame lock connector is designed with a self-locking retention mechanism to secure its connection with the frame lock cable to provide robust connectivity and maximum productivity.

    OpenGL Quad Buffered Stereo Support

    Provide a smooth and immersive 3D Stereo experience for professional applications.

    Ultra-High-Resolution Desktop Support

    Get more Mosaic topology choices with high resolution displays devices with a 32K Max desktop size.

    Professional 3D Stereo Synchronization

    Robust control of stereo effects through a dedicated connection to directly synchronize 3D stereo hardware to an NVIDIA RTX professional graphics card.

    MULTI-GPU TECHNOLOGY SUPPORT

    3rd Generation NVLink

    Connect two RTX A5000 cards with NVLink to double the effective memory footprint and scale application performance by enabling GPU-to-GPU data transfers at rates up to 112.5 GB/s (total bandwidth).

    NVIDIA SLI Technology

    Leverage multiple GPUs to dynamically scale graphics performance, enhance image quality, expand display real estate, and assemble a fully virtualized system.

    SOFTWARE SUPPORT

    NVIDIA Virtual GPU Software

    Support for NVIDIA virtual GPU (vGPU) software allows a personal workstation to be repurposed into multiple high-performance virtual workstation instances enabling remote users, to share resources to drive high-end design, AI, and compute workloads.

    NVIDIA RTX Experience

    NVIDIA RTX Experience delivers a suite of productivity tools to your desktop workstation, including desktop recording in up to 8K, automatic alerts for the latest NVIDIA RTX Enterprise driver updates, and access gaming features. The application is available for download here.

    Software Optimized for AI

    Deep learning frameworks such as Caffe2, MXNet, CNTK, TensorFlow, and others deliver dramatically faster training times and higher multi-node training performance. GPU accelerated libraries such as cuDNN, cuBLAS, and TensorRT delivers higher performance for both deep learning inference and High- Performance Computing (HPC) applications.

    NVIDIA CUDA Parallel Computing Platform

    Natively execute standard programming languages like C/C++ and Fortran, and APIs such as OpenCL, OpenACC and Direct Compute to accelerates techniques such as ray tracing, video and image processing, and computation fluid dynamics.

    Unified Memory

    A single, seamless 49-bit virtual address space allows for the transparent migration of data between the full allocation of CPU and GPU memory.

    NVIDIA GPUDirect for Video

    GPUDirect for Video speeds communication between the GPU and video I/O devices by avoiding unnecessary system memory copies and CPU overhead.

    NVIDIA Enterprise-Management Tools

    Maximize system uptime, seamlessly manage wide-scale deployments, and remotely control graphics and display settings for efficient operations.

  • Specifications

    NVIDIA RTX A5000

    SPECIFICATIONS

    Compatible in all systems that accept an NVIDIA RTX A5000

    Product

    		 NVIDIA® RTX™ A5000

    Architecture

    		 NVIDIA Ampere Architecture

    Process Size

    		 8nm

    Transistors

    		 28.3 Billion

    Die Size

    		 628.4 mm2

    CUDA Cores

    		 8192

    Tensor Cores

    		 256

    RT Cores

    		 64

    Single Precision Performance

    		 27.8 TFLOPS

    RT Core Performance

    		 54.2 TFLOPS

    Tensor Performance

    		 222.2 TFLOPS

    GPU Memory

    		 24 GB GDDR6 with ECC

    Memory Interface

    		 384-bit

    Memory Bandwidth

    		 768 GB/sec

    Display Connectors

    		 4x DisplayPort 1.4a

    NVENC | NVDEC

    		 1x | 2x (+ AV1 decode)

    System Interface

    		 PCI Express 4.0 x16

    Form Factor

    		 4.4" H x 10.5" L Dual Slot

    Thermal Solution

    		 Active Fansink

    Maximum Power Consumption

    		 230 W
    NVIDIA Quadro and RTX Power Guidelines

    Power Connector

    		 1x 8-pin PCIe

    Max Digital Resolution

    		 7680 x 4320 x36 bpp at 60 Hz
    NVIDIA Quadro and RTX Display Resolution Support

    vGPU Software Support

    		 NVIDIA Virtual PC (vPC), NVIDIA Virtual Applications (vApps), NVIDIA RTX Virtual Workstation (vWS), NVIDIA Virtual Compute Server (vCS)

    vGPU Profiles Supported

    		 See vGPU Pricing and Licensing Guide

    NVIDIA 3D Vision and 3D Vision Pro

    		 Support via 3-pin mini DIN

    Frame Lock

    		 Compatible with NVIDIA Quadro Sync II

    NVLink

    		 2-way low profile (2-slot and 3-slot bridges) connects 2x NVIDIA RTX A5000

    NVLink Interconnect

    		 112.5 GB/sec bidirectional

    AVAILABLE ACCESSORIES

    • RTXA6000NVLINK-KIT provides an NVLink connector for the RTX A5000 (or RTX A6000) suitable for standard PCIe slot spacing motherboards, effectively fusing two physical boards into one logical entity with 21504 CUDA Cores, 672 Tensor Cores, 168 RT Cores, and 96 GB of GDDR6 ECC memory, with a bandwidth of 100 GB/Sec. Order PN RTXA6000NVLINK-KIT when ultimate performance and capabilities are required with two RTX A5000 boards (application support required).
    • RTXA6000NVLINK-3S-KIT offers an NVLink connector for the RTX A5000 (or RTX A6000) compatible with motherboards featuring wider PCIe slot spacing. All other features and benefits are identical to the standard slot spacing version.
    • DP-HDMI-THREE-PCK connects the NVIDIA RTX A5000 to HDMI displays at resolutions up to 4K with PNY Part Number DP-HDMI-THREE-PCK. The three included DisplayPort to HDMI adapters are recommended by NVIDIA, provide outstanding image quality, and are built to professional standards.
    • DP-HDMI-SINGLE-PCK connect the NVIDIA RTX A5000 to an HDMI display at resolutions up to 4K with PNY Part Number DP-HDMI-SINGLE-PCK. The included DisplayPort to HDMI adapter is recommended by NVIDIA, provides outstanding image quality, and is built to professional standards.

    SUPPORTED OPERATING SYSTEMS

    • Microsoft Windows 11 (64-bit)
    • Microsoft Windows 10 (64-bit)
    • Red Hat Enterprise Linux 7.x
    • SUSE Linux Enterprise Desktop 15.x
    • OpenSuse 15
    • Fedora 31
    • Ubuntu 18.04
    • FreeBSD 11.x
    • Solaris 11

    MINIMUM SYSTEM HARDWARE REQUIREMENTS

    • Intel Core i5, i7, i9, or Xeon processor or later
    • AMD Ryzen or Epyc class processor or later
    • PCI Express 4.0 x16 (preferred) expansion slot
    • System memory greater than or equal to GPU memory, twice the GPU memory recommended
    • Internet connection for driver installation
    • DisplayPort 1.4a (preferred), HDMI, or DVI compatible display(s)

    PACKAGE CONTAINS

    • NVIDIA RTX A5000 professional graphics card
    • Auxiliary power cable
