RTX Server 8000, Up to 8 x NVIDIA QUADRO RTX 8000 GPU

RTX Server 8000, Up to 8 x NVIDIA QUADRO RTX 8000 GPU

  • SKU: PNYRTX488RTX8K-105F
  • Description

    Overview

    NVIDIA® RTX™ SERVER FEATURING QUADRO RTX HIGH-PERFORMANCE, FLEXIBLE RENDERING IN THE DATA CENTER, WITH QUADRO RTX 8000

    POWER AND FLEXIBILITY FROM DESKTOP TO DATA CENTER

    NVIDIA® RTX™ Server is a highly configurable reference design, validated by NVIDIA®, that provides the power you need to boost rendering performance on desktop, accelerate offline rendering, and provision high-performance virtual workstations and virtual compute servers, all in a single, flexible solution.

    ACCELERATE YOUR ENTIRE RENDERING / COMPUTE PIPELINE

    OFFLINE RENDERING

    Drastically reduce the time required for offline rendering with the power of GPU acceleration with the NVIDIA® RTX™ Server.

    ACCELERATED DESKTOP RENDERING

    Boost local workstation rendering performance and interactivity by connecting to NVIDIA® RTX™ Server and tapping into the power of up to 8 GPUs

    VIRTUAL WORKSTATIONS AND COMPUTE SERVER

    Provision multiple, easy-tomanage virtual workstations / compute servers from a single NVIDIA® RTX™ Server with NVIDIA® GRID™ vDWS / vCS.

    FEATURES

    - Hot-Swap Redundant PSU’s & System Fans
    - Onboard SATA RAID 0/1/5/10 (Intel RSTe)
    - PLX PCIe Switch Topology
    - AMI MegaRAC® SP-X SoC for IPMI:
      • User-friendly Graphics User Interface • Users management
      • Services settings & Sessions control • LDAP settings
      • Power control & voltages, fans and temperatures monitoring
      • Events management (platform events, trap settings, email settings)
      • Serial Over LAN • vKVM & vMedia (launch, configuration)

    Product Specifications

    PNY RTX Server for NVIDIA Quadro RTX 8000 - Product Specifications

    Processors 2 x Intel® Xeon® Scalable Skylake Gold 6226R processors
    (2.9-3.9 GHz; 16 Cores, 32 threads per CPU)
    Socket & Chipset 2 x LGA 3647, Intel® C621
    System Memory 12 x 64GB Samsung 2933MHz DDR4 ECC RDIMM
    Storage 1 x Intel 240GB SATA3 2.5” SSD
    1 x Intel 1.92TB SATA3 SSD (expansion up to 14 drives in total supported)
    Network Controllers 2 x 10GbE LAN ports (Intel® X550-AT2) +
    1 x GbE LAN port dedicated for IPMI (Realtek® RTL8211E)
    Expansions Slots

    8 x PCI-E Gen3 x16 slots (FH / FL / DW)
    1 x PCI-E Gen3 x8 storage mezz. slot
    1 x PCI-E Gen3 x8 LAN mezz. slot
    proprietary mezzanine slots (for storage controller, NIC)

    Front / Back I/O 2 x USB 3.0
    1 x VGA
    1 x Serial
    3 x RJ45
    System Cooling 5+1 x hot-swappable 12cm system fans
    Power Supply 2+1 x 2200W redundant PSU (80 PLUS Platinum)
    Form Factor & Dimensions 4U, 770 x 438 x 176 (D x W x H, mm)
