NVIDIA Professional Graphics For

Scalable Visualization

See The Big Picture with NVIDIA RTX
Make viewing and interacting with large-scale photorealistic graphics and HD or 4K HDR video intensive content simple, powerful and affordable with NVIDIA^® Professional Graphics solutions for Scalable Visualization. Easily utilize multiple displays across use cases ranging from desktops, to expansive digital signage walls, or implement stereoscopic 3D CAVE environments with NVIDIA professional graphics solutions, available through certified partners. NVIDIA professional graphics performance, NVIDIA Quadro Sync II hardware synchronization, and NVIDIA tools and APIs like nView, Mosaic, Warp and Blend, or GPU affinity make NVIDIA GPUs the glue that bonds all of the pieces together into a unified and visually stunning whole.

Example Environments

Collaboration Room

Built with industry standard workstations
Up to 32 displays or projectors
NVIDIA Professional Graphics + NVIDIA Quadro Sync II + Mosaic

Interpretation Desktop

Industry standard workstation
Single 4K, 5K or 8K display
NVIDIA Professional Graphics + nView

Conference Room

Industry standard workstation(s)
Up to 32 displays or projectors
NVIDIA Professional Graphics + NVIDIA Quadro Sync II + Mosaic

Auditorium

Industry standard workstation(s)
Single or multiple 4K projectors
NVIDIA Professional Graphics + NVIDIA Quadro Sync II + Mosaic + Warp and Blend

Network Operation Center

Multiple industry standard workstations or servers
Scale displays or projectors as needed
NVIDIA Professional Graphics + NVIDIA Quadro Sync II + Mosaic + nView

Displays and Projectors

HD, 2K, 4K, 5K, 6K, 8K, HDR (High Dynamic Range) displays and projectors are fully supported by current NVIDIA high-end professional solutions suitable for Scalable Visualization. NVIDIA’s Mosaic technology allows up to 32 displays or projectors to be treated as a single logical entity, dramatically simplifying the creation of ultra-high-resolution video walls, or enabling the deployment of state-of-the-art projector systems; even onto irregular surfaces with NVIDIA Warp and Blend, and projector overlap technology, which utilize the GPU to perform the geometry and intensity adjustments required for even the most exotic multi-projector environments. The result is a true single-display experience and off-the-shelf software will automatically span multiple displays or projectors without modification with NVIDIA Mosaic.

NVIDIA Professional Graphics

Scalable Visualization Solutions

Number of synchronized displays/projectors from a single system with NVIDIA Mosaic

NVIDIA PRO GPU	UP TO 2	UP TO 4	UP TO 8	UP TO 12	UP TO 16	UP TO 32
NVIDIA RTX A6000 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II
NVIDIA RTX A5000 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II
NVIDIA RTX A4000 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II
NVIDIA Quadro RTX 8000 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II
NVIDIA Quadro RTX 6000 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II
NVIDIA Quadro RTX 5000 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II
NVIDIA Quadro RTX 4000 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II
NVIDIA Quadro GV100 + HW Sync	1 GPU	1 GPU	2 GPUs + NVIDIA Quadro Sync II	3 GPUs + NVIDIA Quadro Sync II	4 GPUs + NVIDIA Quadro Sync II	8 GPUs + NVIDIA Quadro Sync II

NVIDIA RTX™ series products excel in environments where cinematic quality rendering with or without an AI assist are required. NVIDIA Quadro GV100 is ideal for use cases where FP64 hardware floating point performance is required or desirable.
